The Efficace 60 Series is a premium, UK-made LED downlight designed for commercial and architectural applications.
Featuring a minimalist die-cast bezel and Philips DLM LED technology, it delivers exceptional efficiency with a 96% specular reflector and 60,000-hour lifespan.
Ideal for offices, retail spaces, and heritage buildings, it offers seamless integration with DALI and Casambi wireless controls, emergency lighting options, and customisable finishes.
Its recyclable design and 5-year warranty underscore a commitment to sustainability and reliability.
📄 Bim File
The Efficace 60 is a UK-made professional LED downlight featuring a minimalist die-cast bezel in RAL 9010 white and a revolutionary 75° specular reflector with 96% optical efficiency.
Designed for commercial and architectural applications, it delivers up to 4800 lumens using Philips DLM LED technology while maintaining a lifespan exceeding 60,000 hours (L70/B10). Ideal for offices, retail spaces, and hospitality venues, it offers universal bezel compatibility for accessories, DALI and wireless controls, and emergency lighting options—all backed by a 5-year warranty and 98% recyclable construction.
96% reflector efficiency: 75° highly specular aluminium reflector maximises light output with minimal energy waste.
Universal bezel (/UB): Accepts decorative accessories (halos, diffusers) for custom aesthetics.
Philips DLM LED technology: Delivers consistent performance with efficacy up to 121 lm/W.
Minimalist die-cast design: Sleek RAL 9010 white bezel for modern architectural integration.
Wireless control (/BTC): Casambi Bluetooth-enabled dimming for flexible lighting management.
Emergency options: Self-test indicators (/EMD, /EMDI) for safety regulation compliance.
UK-manufactured: 5-year warranty with sustainable, 98% recyclable components.
MacAdam <3 SDCM: Tight colour consistency for premium visual environments.
| Specification | Details |
|---|---|
| Model reference | 60.1100.30 to 60.5000.40 |
| Lumen output range | 1075–4800 lm |
| Colour temperatures | 830 (3000K), 840 (4000K) |
| Power consumption | 9.5–46.0 W |
| Luminaire efficacy | 95–121 lm/W |
| Cut-out dimensions | 140 x 140 mm |
| Bezel dimensions | 170 x 170 mm |
| Compliance | L70/B10, 5-year warranty |
| Model Code | Lumens | Colour Temp | Power (tcW) | Efficacy (lm/tcW) |
|---|---|---|---|---|
| 60.1100.30 | 1075 | 3000K | 9.5 | 113 |
| 60.1100.40 | 1150 | 4000K | 9.5 | 121 |
| 60.2000.30 | 1850 | 3000K | 17.5 | 106 |
| 60.2000.40 | 2025 | 4000K | 17.5 | 116 |
| 60.3000.30 | 2850 | 3000K | 30.0 | 95 |
| 60.3000.40 | 3075 | 4000K | 30.0 | 103 |
| 60.5000.30 | 4425 | 3000K | 46.0 | 96 |
| 60.5000.40 | 4800 | 4000K | 46.0 | 104 |
| Category | Option Code | Description | Compatibility |
|---|---|---|---|
| Core Upgrades | |||
| /UB | Universal bezel for accessory mounting | All models | |
| Controls | |||
| /T+DALI | Touch dimming or DALI control gear | All models | |
| /BTC | Casambi wireless dimming | All models | |
| Emergency | |||
| /EM | Emergency remote indicator | All models | |
| /EMD | DALI self-test emergency (remote) | All models | |
| /EMI | Emergency integral indicator | All models | |
| /EMDI | DALI self-test emergency (integral) | All models | |
| Aesthetics | |||
| PV | Custom RAL bezel/black reflector | All models |
| Accessory Code | Description | Use Case |
|---|---|---|
| DA001 | Clear acrylic lens | Unfiltered directional light |
| DA002 | Opal acrylic lens | Soft, diffused illumination |
| DA003 | Clear acrylic square halo | Architectural accent lighting |
| DA004 | Opal acrylic square halo | Subtle decorative projection |
| LSOH/LSF Cable | Low-smoke, zero-halogen wiring | Fire-safe installations |
| Custom Bezels | Any RAL colour (via PV) | Brand/thematic coordination |
Corporate lobbies: Model 60.3000.40 (3075 lm) with /UB and DA003 halo for premium ambience.
Retail displays: High-output 60.5000.40 (4800 lm) paired with clear acrylic (DA001) for product highlighting.
Hospitality ceilings: Universal bezel (/UB) with opal square halo (DA004) for elegant diffusion.
Public buildings: Emergency-ready 60.2000.30 (1850 lm) with /EMDI for compliant corridors.
113 Series: Tridonic-based tunable white downlights for dynamic lighting.
78 & 96 Series: Compact 130mm downlights for space-constrained installations.
100 Series: 240mm high-output downlights for large commercial areas.
📄 Bim File
Yes, all of our luminaires are available with dimmable LED drivers.
Yes, all Lumenloop luminaires are supplied with compatible drivers to ensure optimal functionality and straightforward installation.
We use premium driver brands like Tridonic and Philips to ensure they have long life expectancies.
All our products are proudly designed and manufactured in the UK, ensuring the highest quality standards.
Our products are designed for various environments, with IP ratings from IP20 for indoor applications to IP65 for harsher conditions such as outdoor or industrial spaces.
Yes, our luminaires are designed to integrate seamlessly into retrofit projects, making it easy to upgrade existing lighting systems with minimal disruption.
Yes, Lumenloop’s industrial range of luminaires are built to withstand demanding environments, including high-moisture and high-heat settings.
Many of our products are designed with robust construction and high-quality materials that ensure reliability and durability in challenging conditions.
Yes. We offer 600×600 LED panels suitable for standard grid ceilings as well as selected specialist ceiling systems.
We also offer frames for SAS or Armstrong metal ceilings.
Yes. Most of our luminaires can be supplied with integrated emergency functionality, typically with a 3-hour duration.
Yes, we offer luminaires which can be supplied with DALI emergency self-test options where required.
This can help simplify emergency testing and monitoring as part of a wider lighting control or building management strategy.
We offer both maintained and non-maintained emergency options, depending on how the space is used.
While most standard products are available with a 3 hour non-maintained emergency pack, we also have standalone emergency lighting products with the choice of maintained and non-maintained.
Yes. Emergency functionality can be integrated into a wide range of luminaires, including downlights and panels.
This depends on layout, escape routes, and risk areas rather than just floor area. We can advise based on your drawings or requirements.
For a more detailed recommendation, please refer to our emergency lighting tool.
Yes. Selected luminaires can be supplied with self-test or DALI emergency options for automated testing and reporting.
Lead times vary depending on the product and the level of customisation required, but because most Lumenloop luminaires are made to order, we can usually give a clear lead time once the specification is confirmed.
Standard product: Typically 10 working days
Custom (e.g. bespoke RAL colour): Typically 20-30 working days
Special (bespoke): Typically between 6 – 8 weeks
Yes, we work closely with clients to develop bespoke lighting solutions tailored to their specific needs and design requirements.
Please reach out to us at info@lumenloop.co.uk
Yes, we can provide photometric LDT files to support lighting calculations, these are available to download on every product page.
Yes, Lumenloop luminaires are available in a wide range of colours and finishes to suit diverse design needs.
Most of our luminaires are customizable with a variety of RAL colour options, allowing you to match your lighting seamlessly with your interior decor or branding requirements.
This includes (but is not limited to) popular finishes such as RAL9010 (Pure White), RAL9003 (Signal White), RAL9005 (Jet Black), and RAL9016 (Traffic White), among many others.
In many cases, yes. Because products are made to order, we can often match key parameters such as size, output, or appearance.
You can either use our AI lighting product finder (just click on the ‘specify with AI‘ button in bottom-right corner or simply email us at info@lumenloop.co.uk
Our luminaires are designed to align with relevant UK standards, including BS EN 12464-1 for workplace lighting and BS 5266 for emergency lighting.
Yes, many of our luminaires incorporate recycled components, supporting our commitment to sustainable manufacturing.
Look out for the ‘98% recycled‘ product icon for those luminaires that are mostly made from recycled materials.
Yes, as a WEEE-certified member of Recolight, we offer free recycling services for old lighting fixtures to support sustainable waste management.
Yes. Many of our products are designed to be upgraded or refurbished, extending their usable life and reducing replacement costs.
Yes, Lumenloop offers refurbishment services for older light fittings, helping to extend their lifespan and improve energy efficiency.
Our ‘UK Renew & Reuse‘ workshop can upgrade your existing luminaires with the latest technology, such as LED retrofitting, modern dimming controls, and energy-efficient drivers, to ensure compliance with current standards and enhance performance.
Yes. Our luminaires are designed using circular principles, including modular construction and long-life components to reduce waste over time.
We openly publish product TM66 data for full transparency.
