Guard 132 Architectural LED Downlight: Professional-grade indoor lighting solution with single, twin, and triple configurations.
Die-cast aluminum construction, IP44 protection, up to 900 lumens output. Tridonic LED engine, 40° precision reflector, 55,000-hour lifespan. DALI, Casambi, and SwitchDIM compatible.
Ideal for offices, retail, hospitality, and healthcare environments.
📄 Bim File
The Guard 132 is an architectural LED downlight designed for commercial and residential spaces requiring precise, glare-free illumination.
Featuring a square die-cast aluminium bezel and IP44-rated protection, it combines discreet aesthetics with robust performance.
Available in single, twin, and triple LED configurations, this downlight offers scalable brightness and optional Ra90 high colour rendering for accurate light reproduction.
Engineered with Tridonic technology, it supports dimming protocols and emergency lighting conversions, ensuring compliance with modern lighting demands.
Square bezel design: Minimalist RAL 9003 white or RAL 9005 black finish for seamless integration into ceilings.
Modular configurations: Choose single, twin, or triple LED engines to suit varying lumen requirements.
High CRI Ra90 option: Enhanced colour accuracy for retail, galleries, and healthcare environments.
IP44-rated lens: Protects against dust and moisture in humidity-prone areas.
40° precision reflector: Uniform light distribution with minimal glare.
Tridonic LED engine: Reliable performance with a lifespan exceeding 55,000 hours (L90/F10).
Thermal management: Super-fin die-cast heatsink ensures optimal heat dissipation.
Flexible control options: Compatible with SwitchDIM, DALI, DSI, and Casambi wireless dimming.
Emergency-ready: Optional EM conversion with self-test and status indicators.
Plaster-in or surface mounting: Versatile installation for flush or suspended ceilings.
| Specification | Details |
|---|---|
| Model References | 132.001 to 132.306 |
| Lumen Output Range | 600–2700 lumens |
| LED Configurations | Single, Twin, Triple Engines |
| Power Consumption | 6.5–30.0 W |
| Colour Temperatures | 830 (warm), 840 (neutral), 927 (cool) |
| Bezel Dimensions | 154 x 154 mm (surface) |
| Cut-out Dimensions | 81 x 81 mm (plaster-in) |
| Finish Options | White (RAL 9003), Black (RAL 9005) |
| Protection Rating | IP44 |
| Version | Code Suffix | Description |
|---|---|---|
| SwitchDIM/DALI/DSI | /ECO | Multi-protocol dimming integration |
| 20° narrow beam reflector | /NB | Focused illumination for accent zones |
| Ra90 high colour rendering | /9 | Enhanced colour accuracy (CRI ≥90) |
| EM conversion | /EM | Basic emergency lighting mode |
| DALI self-test EM conversion | /EMD | Automated testing via DALI protocol |
| Casambi wireless control | /BTC | Bluetooth-enabled dimming and scenes |
| Plaster-in bezel | /PI | Flush ceiling installation |
| Model Code | Finish | Configuration | Testing Option |
|---|---|---|---|
| 132.001 | White (RAL 9003) | Single | Add suffix (e.g., /ECO) |
| 132.201 | White (RAL 9003) | Twin | Add suffix (e.g., /9) |
| 132.301 | White (RAL 9003) | Triple | Add suffix (e.g., /BTC) |
| 132.005 | White (RAL 9003) | Single | Add suffix (e.g., /EMD) |
| 132.305 | Black (RAL 9005) | Triple | Add suffix (e.g., /NB) |
Note: All models available in black bezel (add /BK). Specify options as suffixes to the base model code.
Office ceilings and conference rooms
Retail displays and boutique stores
Hospitals and clinical settings
Museums and art exhibition spaces
Hospitality lounges and restaurants
Educational facilities and libraries
Residential kitchens and hallways
Energy-efficient modular design reduces power consumption.
Long lifespan minimises maintenance and replacement costs.
Customisable beam angles for task or ambient lighting.
Compatible with smart building systems for automated control.
Sleek, low-profile design enhances modern interior aesthetics.
