Matt black darklight baffle
Supports minimum glare - RAL 9005.
Edge LED downlight
The Edge Architectural LED Wall Washer is designed to deliver sharp, consistent illumination, making it an ideal solution for highlighting walls and architectural features.
Outputs up to 1325 lm
Output reference for specification and comparison.
IP44 protective lens
Supports controlled distribution and visual comfort in the finished ceiling.
Thermally optimised die-cast heatsink
Supports the selected specification.
Model references
EDGE.001
Life >55,000 hours (L90 / F10)
Long-life LED performance.
Outputs up to 1325 lm
Output reference for specification and comparison.
Specification resources
Download Datasheet, Installation Guide, Photometric Data, BIM File
Luminaire type
LED downlight
Life >55,000 hours (L90 / F10)
Long-life LED performance.
Matt black darklight baffle
Supports minimum glare - RAL 9005.
Download Datasheet
Technical datasheet for specification review.
Installation Guide
Installation guide for site coordination.
Photometric Data
Photometric data pack for lighting calculations.
BIM File
BIM coordination file for project drawings.
Project selection
Available luminaire options and accessories are shown below.
Configure For Enquiry
Configure Edge for enquiry.
Select the output, optic, finish, control gear and accessories needed for the project, then send the configuration to Lumenloop for specification support.
Configured Specification
Selected Edge specification.
Selection reference
EDGE.001
Selection reference
EDGE.001
Technical Description
LED downlight specification for Edge.
The Edge Architectural LED Wall Washer is designed to deliver sharp, consistent illumination, making it an ideal solution for highlighting walls and architectural features. With an 85 mm diameter and an 81 mm cut-out, the Edge provides an asymmetric light distribution that ensures even coverage with a well-defined cut-off
Performance and installation details include life >55,000 hours (L90 / F10). This section covers output, optics, mounting and control requirements.
Supporting resources include datasheet, Installation guide, Photometric data and BIM file, where published.
Specification-led LED downlight features.
- Matt black darklight baffle: Supports minimum glare - RAL 9005.
- Outputs up to 1325 lm: Output reference for specification and comparison.
- IP44 protective lens: Supports controlled distribution and visual comfort in the finished ceiling.
- Thermally optimised die-cast heatsink: Supports the selected specification.
- Casambi Bluetooth wireless network option: Suitable for a range of control and emergency options.
- Low profile die-cast aluminium: Bezel - White RAL 9003
- Tridonic LED engine and driver system: Gives the product range a recognised LED and driver platform.
- Life >55,000 hours (L90 / F10): Long-life LED performance.
Body And Trim Detail
Edge quick technical reference.
The Edge Architectural LED Wall Washer is designed to deliver sharp, consistent illumination, making it an ideal solution for highlighting walls and architectural features.
Key specification points include life >55,000 hours (L90 / F10).
Project notes include Controls: Mains dimming /MDIM, DALI / SwitchDIM / DSI /ECO and Casambi wireless /BTC. Emergency: 3-hour emergency /EM, Maintained emergency /EMI, Self-test / DALI emergency /EMD and DALI emergency /EMDI. Supporting files include datasheet, Installation guide and Photometric data.
Specification Choices
Edge specification options.
Output and CCT
EDGE.001600 lm | 8.0 W | 2700K | White RAL 9003 | Lumen package: 600lm
Output and CCT
EDGE.002675 lm | 6.5 W | 3000K | White RAL 9003 | Lumen package: 675lm
Output and CCT
EDGE.003700 lm | 6.5 W | 4000K | White RAL 9003 | Lumen package: 700lm
Output and CCT
EDGE.004850 lm | 10.0 W | 2700K | White RAL 9003 | Lumen package: 850lm
Output and CCT
EDGE.005850 lm | 8.0 W | 3000K | White RAL 9003 | Lumen package: 850lm
Output and CCT
EDGE.006900 lm | 8.0 W | 4000K | White RAL 9003 | Lumen package: 900lm
Options And Accessories
Edge options, finishes and controls.
/MDIM/ECO/BTC
Mains dimming /MDIM; DALI / SwitchDIM / DSI /ECO; Casambi wireless /BTC.
/EM/EMI/EMD/EMDI
3-hour emergency /EM; maintained emergency /EMI; self-test / DALI emergency /EMD; DALI emergency /EMDI.
Specification reasons
Why specify Edge?
Optics
Matt black darklight baffle
Supports minimum glare - RAL 9005.
Performance
Outputs up to 1325 lm
Output reference for specification and comparison.
Optics
IP44 protective lens
Supports controlled distribution and visual comfort in the finished ceiling.
Controls
Thermally optimised die-cast heatsink
Supports the selected specification.
Controls
Casambi Bluetooth wireless network option
Suitable for a range of control and emergency options.
Options
Low profile die-cast aluminium
Bezel - White RAL 9003
Product FAQs
Edge specification questions.
Specification notes for contractors, consultants and buyers checking LED downlight options before ordering.
What makes Edge different from a standard LED downlight?
The Edge Architectural LED Wall Washer is designed to deliver sharp, consistent illumination, making it an ideal solution for highlighting walls and architectural features. With an 85 mm diameter and an 81 mm cut-out, the Edge provides an asymmetric light distribution that ensures even coverage with a well-defined cut-off
Which ceilings or mounting conditions should be checked for Edge?
Check the mounting method, ceiling construction, access space and installation guide before the luminaire is added to the final schedule.
Which outputs, wattages and colour temperatures are available?
Outputs up to 1325 lm: Output reference for specification and comparison. Life >55,000 hours (L90 / F10): Long-life LED performance. Output, colour temperature, control gear and emergency options vary by configuration.
What controls and emergency options can be specified?
Controls: Mains dimming /MDIM, DALI / SwitchDIM / DSI /ECO and Casambi wireless /BTC. Emergency: 3-hour emergency /EM, Maintained emergency /EMI, Self-test / DALI emergency /EMD and DALI emergency /EMDI. Confirm compatibility with the project control strategy, emergency schedule and selected base model before quotation.
Can finishes, accessories or product variations be specified?
Finish, accessory and project variation requirements should be confirmed before quotation, especially where non-standard colours, plug-and-socket arrangements or controls are required.
Are photometric, BIM or installation files available?
Available resources include datasheet, Installation guide, Photometric data and BIM file for specification reference and product selection.
What lead time should be allowed for Edge?
Lead time depends on quantity, finish, control gear, emergency conversion and current production capacity. Confirm the current project lead time with Lumenloop before placing an order.
Product Support
Check product options and datasheets.
Share the selected code, room type, control preference and any accessory requirements. Lumenloop can provide datasheets, option notes and supporting files for the selected fitting.
