The 171 Series LED downlight combines premium Tridonic technology with elegant architectural design.
Featuring advanced DALI control options, multiple beam angles, and outputs up to 1275lm, this compact ø76mm bezel luminaire delivers professional-grade illumination with exceptional efficiency.
Each fixture is manufactured in the UK to exacting standards and backed by a comprehensive 5-year warranty, making it the ideal choice for architects and lighting designers seeking a reliable, high-performance lighting solution.
📄 Bim File
The Axis 171 Series is a premium miniature LED downlight designed for high-specification architectural interiors.
Engineered for discreet integration into commercial and residential ceilings, the 171 delivers high-performance illumination through a professional Tridonic SLA Essence engine.
With lumen outputs up to 1275lm, colour temperature options across 2700K to 4000K, and compatibility with DALI, wireless and emergency systems, this luminaire meets demanding lighting requirements. Manufactured to the highest standards, the 171 Series supports full compliance with UK and EU lighting regulations.
Tridonic SLA Engine: Delivers consistent, high-quality light with excellent reliability.
Miniature Cut-out: Compact ø67mm opening for clean, minimal ceiling presence.
High Output Options: Lumen packages from 725lm to 1275lm for varied lux levels.
Colour Temperature Choice: Available in 2700K, 3000K, and 4000K for tailored ambience.
Long Lifespan: Rated to L70/B50 @ >50,000 hours for reduced maintenance cycles.
MacAdam 3-Step Colour: Ensures uniform colour quality across installations.
Architectural Finish: Die-cast bezel in RAL 9016 white or RAL 9005 black.
Advanced Controls: Supports DALI, Casambi wireless and emergency gear.
Optional Beam Angles: 12°, 24° and 36° lens options for flexible light control.
British Manufacturing: Designed and made in the UK with a 5-year warranty.
| Specification | Details |
|---|---|
| Model Reference | 171.001 to 171.009 |
| Lumen Output | 725lm – 1275lm |
| Correlated Colour Temp | 2700K, 3000K, 4000K |
| Light Engine | Tridonic SLA Essence |
| Operating Power | 9.5W / 10.5W / 14.0W |
| Engine Efficacy | Up to 91 llm/tcW |
| Cut-out Diameter | ø67mm |
| Bezel Diameter | ø76mm |
| Finish Options | White (RAL 9016), Black (RAL 9005) |
| Compliance | UKCA, CE, RoHS |
| Version | Code Suffix | Description |
|---|---|---|
| Mains Dimmable | /MDIM | Phase-cut dimmable driver |
| DALI Control | /ECO | SwitchDIM, DALI, or DSI integration |
| Wireless | /BTC | Casambi Bluetooth mesh dimming system |
| Emergency | /EM | Standard emergency with remote indicator |
| DALI EM | /EMD | DALI addressable/self-test emergency driver |
| Wireless EM | /EMM | Mesh-based wireless emergency operation |
| Model Code | Finish | Testing Option |
|---|---|---|
| 171.001 | /WH, /BL | /MDIM only |
| 171.004 | /WH, /BL | /MDIM, /ECO, /BTC, /EM, /EMD, /EMM |
| 171.007 | /WH, /BL, /BLT | Full option range |
Note: Models 171.001–003 are not compatible with ECO, BTC, or EM options.
High-end residential interiors
Hospitality and boutique hotels
Premium retail environments
Corporate and boardroom spaces
Galleries and exhibition areas
Reception and atrium zones
Design-led commercial spaces
Restaurants and fine dining settings
Reduced energy consumption via high efficacy
Minimal maintenance with long-life engine
Broad system integration compatibility
Suitable for sustainable building standards
Made in the UK with expert technical support
