1050 to 4700 llm
Eight published 93 Series rows cover 3000K and 4000K outputs across 9.5 W to 46.5 W packages.
Eclipse IP54 LED downlight
Eclipse is a recessed 93 Series LED downlight with a reduced-profile RAL 9016 bezel, satin etched reflector, Philips LED and driver system, and output options from 1050 to 4700 luminaire lumens.
Control suffixes
Use /T+DALI or /BTC, with /EM, /EMD, /EMI or /EMDI where emergency provision is required.
IP54 and IP65 options
The current datasheet publishes the /54 sealed clear lens and the /65 bezel option against the Eclipse range.
Lumen maintenance
L70/B10 @ 60,000h
Model references
93.1100.30 to 93.5000.40
Output range
1050 to 4700 llm
Mounting
Recessed | 222 mm cut-out
Options
/T+DALI | /BTC | /54 | /65
Output range
1050 to 4700 llm across eight published 93 Series model references.
Colour temperature
3000K and 4000K model rows are published on the latest datasheet.
Finish
Reduced profile bezel in RAL 9016 white
Mounting
Recessed | 222 mm cut-out | 232 mm bezel
Download Datasheet
Technical datasheet for specification review.
Photometric Data
Photometric data pack for lighting calculations.
BIM File
BIM coordination file for project drawings.
Project selection
Available luminaire options and accessories are shown below.
Configure For Enquiry
Configure Eclipse for enquiry.
Select the required 93 Series model reference and any control, ingress or emergency suffixes, then send the compiled code to Lumenloop for quotation or specification support.
Configured Specification
Selected Eclipse specification.
Selection reference
93.1100.30
Selection reference
93.1100.30
Technical Description
Eclipse 93 Series LED downlight specification.
Eclipse is a recessed 93 Series LED downlight with a reduced-profile RAL 9016 bezel, satin etched reflector and Philips LED and driver system. The current datasheet lists eight standard model references from 93.1100.30 to 93.5000.40.
Those rows cover 1050 to 4700 luminaire lumens across 3000K and 4000K versions, with luminaire power from 9.5 W to 46.5 W and efficacy from 93 to 121 llm/tcW. Use the published 93 Series rows when confirming output and colour temperature on the schedule.
Suffix options on the latest datasheet include /T+DALI and /BTC control gear, /54 sealed clear lens, /65 IP65 bezel option, and emergency /EM, /EMD, /EMI and /EMDI. The same sheet also records the recessed cut-out and bezel dimensions for coordination.
Specification-led IP54 LED downlight features.
- Reduced profile bezel: Published in RAL 9016 white on the current Eclipse datasheet.
- Satin etched reflector: Source-backed optic detail for the Eclipse range.
- Published output range: 1050 to 4700 llm across eight standard model references.
- 3000K and 4000K rows: Match the selected model reference to the required colour temperature before quotation.
- Philips LED and driver system: Listed on the latest 93 Series datasheet.
- Control and emergency suffixes: /T+DALI, /BTC, /EM, /EMD, /EMI and /EMDI are all published options.
- IP54 and IP65 options: The latest sheet lists /54 for the sealed clear lens and /65 for the IP65 bezel.
- Lumen maintenance: L70/B10 @ 60,000h.
Body And Trim Detail
Eclipse quick technical reference.
Eclipse uses a recessed 93 Series body with a reduced-profile RAL 9016 bezel, satin etched reflector and Philips LED and driver system.
Check the published 222 mm cut-out, 232 mm bezel and optional 237 mm IP65 bezel dimensions against the ceiling detail before ordering.
Control and emergency suffixes on the latest datasheet include /T+DALI, /BTC, /EM, /EMD, /EMI and /EMDI, alongside the /54 sealed lens and /65 bezel options.
Options And Accessories
Available Eclipse options.
/T+DALI, /BTC
/54 sealed clear lens, /65 IP65 bezel option
/EM, /EMD, /EMI, /EMDI
Published cut-out tolerance +/- 4 mm for easier retro-fitting.
Specification Choices
Eclipse specification options.
Output and CCT
93.1100.301050 llm | 9.5 W | 3000K
Output and CCT
93.1100.401150 llm | 9.5 W | 4000K
Output and CCT
93.2000.301825 llm | 17.5 W | 3000K
Output and CCT
93.2000.401975 llm | 17.5 W | 4000K
Output and CCT
93.3000.302775 llm | 30.0 W | 3000K
Output and CCT
93.3000.403025 llm | 30.0 W | 4000K
Output and CCT
93.5000.304325 llm | 46.5 W | 3000K
Output and CCT
93.5000.404700 llm | 46.5 W | 4000K
Specification reasons
Why specify Eclipse?
Output range
Eight 93 Series model rows
Source-backed 93 Series references span 1050 to 4700 llm in 3000K and 4000K versions.
Platform
Philips LED and driver system
The current datasheet keeps the LED and driver platform explicit for specification use.
Optics
Satin etched reflector
The reflector detail is published as a standard Eclipse feature.
Ingress
IP54 and IP65 options
Use /54 for the sealed clear lens or /65 for the IP65 bezel option.
Emergency
Published emergency suffixes
/EM, /EMD, /EMI and /EMDI stay aligned with the current 93 Series datasheet.
Performance
L70/B10 @ 60,000h
Use the published lumen-maintenance figure when planning maintenance intervals.
Product FAQs
Eclipse specification questions.
Specification notes for contractors, consultants and buyers checking the current 93 Series Eclipse downlight data before ordering.
What defines Eclipse in the 93 Series range?
Eclipse is a recessed 93 Series LED downlight with a reduced-profile RAL 9016 white bezel, satin etched reflector, Philips LED and driver system, IP54 and IP65 options, and published control and emergency suffixes.
Which cut-out and bezel dimensions should be checked?
The latest datasheet shows recessed mounting with a 222 mm cut-out, a 232 mm bezel, and a 237 mm IP65 bezel option. Check the published dimensions drawing before finalising the ceiling detail.
Which outputs, wattages and colour temperatures are available?
The current 93 Series datasheet lists eight standard model references from 93.1100.30 to 93.5000.40. Those rows cover 1050 to 4700 luminaire lumens, 9.5 W to 46.5 W, and 3000K or 4000K options.
What controls and emergency options can be specified?
Published suffixes on the latest datasheet include /T+DALI and /BTC for control gear, plus /EM, /EMD, /EMI and /EMDI for emergency variants.
Which IP and bezel options can be specified?
The latest datasheet lists a reduced-profile bezel in RAL 9016 white, an IP54 sealed clear lens suffix /54, and an IP65 bezel option /65. The same sheet notes +/- 4 mm cut-out tolerance for retrofit work.
Are datasheet, photometric and BIM files available?
Yes. The current resource set for Eclipse includes the latest datasheet PDF, the 93-LDT photometric ZIP and the 93-BIM ZIP.
What lead time should be allowed for Eclipse?
Lead time depends on quantity, finish, control gear, emergency conversion and current production capacity. Confirm the current project lead time with Lumenloop before placing an order.
